FLY ALLUMINIUM - Aluminium single doors

Single or double acting door with aluminium frame.

FLY ALUMINIUM

Minimum thickness, beauty and functionality without limits: the hinged door with anodised aluminium frame and steel panel combines robustness and elegance.
Ideal solution for emergency exits, it is possible to equip it with a panic handle in compliance with standards, as well as various accessories such as Visual lights s, safety locks, etc.

TECHNICAL PRODUCT INFORMATION

Door consisting of a 40 mm thick panel with aluminium containment profiles and perimeter aluminium rebate frame, with seat for seals, anchored to the wall compartment by means of expansion plugs. The panel is completely covered with smooth or peeled sheets obtained through a continuous rolling process, in galvanized steel SENDZIMIR system, thickness 8/10, followed by phosphating and the application of 5 Micron thick primer on both faces. On the external side is applied the finishing varnish with a thickness of 20 Micron. This pre-painting offers, without any alteration, the resistance of 400 hours in a salt spray chamber. Finally, we prevent scratches by applying adhesive film to be removed after installation.

The insulation is guaranteed by the injection of self-extinguishing polyurethane foam according to DIN 4102 class B2, with a density of not less than 43/45 kg/m³, obtained through an under-press expansion process that ensures a high degree of thermal insulation. Hinges and handle are made of aluminium alloy In the case of installations in compartments not suitable to receive doweled doors, provide for the use of a counterframe with walling clamps, in tubular black steel dim.40x15x1.5.



Fields of application with temperatures between +4° C and +40° C

CE Marking EN 13241-1 (CPD)

Acoustic isolation UNI EN 717-1; R=28dB

Thermal transmittance according to standard 13241-1 U=1.7W / m²K



Optionals:

  • Panic bars
  • Panic bars with electric striker
  • Electric locks
  • Security locks
  • Door Closing Pumps
  • Unified cylinders
  • Visual lights with safety glass
  • Perimeter padding
  • Ventilation grids
  • Stainless steel construction
  • Panel pre-painted colours : B.co/similar grey RAL 9002, Aluminium white RAL 9006, Aluminium grey RAL 9007, Fire red RAL 3000, Moss green RAL 6005, Gentian blue RAL 5010, Pure white RAL 9010, Traffic white RAL 9016, Brown earth RAL 8028, Anthracite grey RAL 7016.
  • Painting in RAL colour of your choice

DOWNLOAD DATA SHEET

SPECIFICATIONS

Made with the same production process as the doors, the hinged pedestrian door has all the quality features of Moreschi's products.

Maximum achievable dimensions:
single door 1300x2500
double leaf door 2500x2500

Aluminium frame and profiles: black electrocolour or natural aluminium.
Colour: standard B.co/grey panel similar to RAL 9002.
B.co/Grey RAL9002, Aluminium white RAL 9006, Aluminium grey RAL 9007, Fire red RAL 3000, Moss green RAL 6005, Gentian blue RAL 5010, Pure white RAL 9010, Traffic white RAL 9016, Earth brown RAL 8028, Anthracite grey RAL 7016.

Indoor and outdoor use.
